| TYPE | DESCRIPTION |
| Mfr | Switchcraft / Conxall |
| Series | Hi-D® 11* |
| Package | Bulk |
| Product Status | ACTIVE |
| Features | Mounting Hardware, Thread Lock |
| Voltage - Rated | 48VDC |
| Connector Type | Phone Jack |
| Gender | Female |
| Mounting Type | Panel Mount, Through Hole |
| Shielding | Unshielded |
| Thread Size | 3/8"-32 |
| Operating Temperature | -20°C ~ 65°C |
| Panel Hole Size | 0.375" (9.52mm) |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Internal Switch(s) | Single Switch |
| Signal Lines | Mono |
| Termination | Solder Eyelet(s) |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Contact Material | Brass |
| Housing Material | Polyester, Glass Filled |
| Body Material | Brass |
| Body Color | Silver, Black |
| Contact Material - Plating | Tin |
| Actual Diameter | 0.250" (6.35mm) |
| Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone |
| Current Rating (Amps) | 3 A |
